– PF>0.95
– Aluminum body
– +80 llm/W efficiency
– With high efficiency factor and affordable price, it has the fastest payback period.
| Product Code Ürün Kodu |
Power Güç (W) |
Color Temp. Işık Rengi (K) |
Lum. Out. Işık Akısı (≥lm) |
LumenEff. Verimlilik (lm/W) |
Fixture Dimensions Armatür Ölçüleri (mm) a / b / h |
Weight Ağırlık (kg) |
Pack. Qty Ambalaj Adedi |
||
|---|---|---|---|---|---|---|---|---|---|
| GCP 1010PR SS30 | 2x5W SMD LED | 3000K | 800 | >80 | 100 | 135 | 100 | – | 1 |
| GCP 1010PR SS40 | 2x5W SMD LED | 4000K | 800 | >80 | 100 | 135 | 100 | – | 1 |
| GCP 1010PR SS60 | 2x5W SMD LED | 6500K | 800 | >80 | 100 | 135 | 100 | – | 1 |
.
| Body | Aluminum |
| IP Rating | IP65 |
| IK Rating | IK08 |
| Flame Protection | – |
| Cable Gland | – |
| Cable | – |
| Ral Code | 9005/9006/9016 |
| Mounting Type | Surface Mounted |
| Light Source | Mid Power Led |
| Reflector | – |
| Lens | – |
| Diffuser | Opal |
| Color Rendering Index (CRI) | >80 |
| Color Temperature | 3000K / 4000K / 6500K |
| Photobiological Risk | – |
| Beam Angle | – |
| Input Voltage | 220-240V AC |
| Frequency | 50-60Hz |
| Class | I |
| System Lifetime | >30.000h |
| Power Factor | >0,95 |
| Operating Temperature | -20°C / +45°C |
| Standards | EN60598-2-1 |
.
